Gold Note Headphone Amplifier HP-10
$2,495.00
Product Details
Pure analog Class-A headphone amplifier
The Gold Note HP-10 delivers reference Class-A Dual-Mono performance through 4 headphone outputs: 3.5mm/6.3mm unbalanced, 4.4mm/4-pin XLR balanced (10W max power). All-analog signal path with discrete components and real-time Studio processing.
Complete Studio analog processing
4 Crossfeed modes recreate natural loudspeaker soundstage. Harman Curve headphone EQ optimization, Superflat high-frequency linearization, adjustable Damping Factor (High/Low), 0/180° phase inversion. L/R Balance compensates driver mismatch.
Universal headphone compatibility
10W maximum power supports all headphone types/impedances. Mono operation (L+R sum, L-only, R-only) with channel swapping. Trigger In/Out system synchronization. Bypass mode maintains preamp wiring when switching between headphones/speakers.
Flexible line-level connectivity
Analog inputs: RCA unbalanced (5Vrms max), XLR balanced (8Vrms max). Line outputs: RCA/XLR balanced (apply all Studio processing). Perfect companion for PH-10/PH-5.2 phono stages and our complete vinyl ecosystem.
Intuitive 3-way control
Touchscreen display, SKC rotary knob, multifunctional remote control. Real-time adjustments during playback. 20Hz-20kHz ±0.3dB response, 0.015% THD+N @1kHz, 110dB SNR. Compact 200×80×260mm chassis (3.5kg net).
Essential 10 Series headphone solution
Matches PA-10 amplifiers and our complete analog chain. PSU-10 EVO external power supply upgrade available. Available exclusively at Vinyl Sound Buffalo, NY.
Technical Specifications
| Parameter | Value |
|---|---|
| Amplifier Design | Class-A Dual-Mono (pure analog) |
| Frequency Response | 20Hz-20kHz ±0.3dB |
| THD+N | 0.015% @1kHz |
| SNR | 110dB |
| Headphone Outputs | 3.5mm, 6.3mm (unbalanced); 4.4mm, 4-pin XLR (balanced) |
| Line Outputs | 1× RCA unbalanced, 1× XLR balanced |
| Analog Inputs | 1× RCA (5Vrms max), 1× XLR balanced (8Vrms max) |
| Power Output | 10W max (all headphones) |
| Processing | 4× Crossfeed modes, Harman Curve, Superflat, Variable DF, Phase invert, Balance |
| Power Consumption | Max 25W |
| Dimensions (WxHxD) | 200 × 80 × 260mm |
| Weight | 3.5kg net / 4.5kg boxed |
Reference headphone listening platform
Upgrade path: PSU-10 EVO external power supply. Perfect foundation for high-end headphone systems. Contact Vinyl Sound Buffalo for Studio feature optimization and headphone matching.
