Gold Note HP-5.2 Headphone Amplifier
$1,295.00
Product Details
Redefined personal listening excellence
The Gold Note HP-5.2 delivers Class-A Dual-Mono performance in compact 200×80×260mm chassis. Features SABRE ES9023 DAC, Bluetooth 5.2 HD aptX, 4 headphone outputs, and complete analog Studio processing for ultimate headphone optimization.
SABRE ES9023 digital conversion
Premium SABRE ES9023 DAC via USB-C (PCM 48kHz) + Bluetooth 5.2 HD aptX 24-bit wireless. 20Hz-20kHz ±0dB response, 0.015% THD+N @1kHz, 105dB SNR. Real-time adjustments via touchscreen without interrupting playback.
Complete Studio analog processing
Adjustable Crossfeed recreates loudspeaker soundstage (full spectrum/highs/mids/lows). Harman Curve headphone EQ, Superflat high-frequency linearization, variable Damping Factor, Gain (low/mid/high), L/R Balance control.
Universal headphone compatibility
5W maximum power drives IEMs to high-impedance planars effortlessly. 4 outputs: 3.5mm/6.3mm unbalanced, 4.4mm/4-pin XLR balanced. Mono/Stereo operation with channel swapping. Trigger In/Out system synchronization.
Flexible line connectivity
Analog inputs: RCA (5Vrms max), XLR balanced (8Vrms max). Line outputs: RCA/XLR balanced (apply Studio settings). Bypass mode maintains preamp wiring. Perfect match for PH-5.2 and our vinyl ecosystem.
5 Series compact design
3kg net aluminum chassis optimized for vibration isolation. Power consumption <25W. Multifunctional remote + touchscreen + SKC knob control. Available exclusively at Vinyl Sound Buffalo, NY.
Technical Specifications
| Parameter | Value |
|---|---|
| Amplifier Design | Class-A Dual-Mono |
| Frequency Response | 20Hz-20kHz ±0dB |
| THD+N | 0.015% @1kHz |
| SNR | 105dB |
| DAC | SABRE ES9023 |
| Digital Inputs | USB-C (PCM 48kHz), Bluetooth 5.2 HD aptX 24-bit |
| Headphone Outputs | 3.5mm, 6.3mm, 4.4mm balanced, 4-pin XLR |
| Line Outputs | RCA unbalanced, XLR balanced |
| Analog Inputs | RCA (5Vrms), XLR balanced (8Vrms) |
| Power Output | 5W max (all headphones) |
| Processing | Crossfeed (4 modes), Harman Curve, Superflat, Variable DF/Gain |
| Power Consumption | Max 25W |
| Dimensions (WxHxD) | 200 × 80 × 260mm |
| Weight | 3kg net / 4kg boxed |
Ultimate personal listening platform
Perfect companion for 5 Series electronics and complete Gold Note systems. Contact Vinyl Sound Buffalo for headphone matching and Studio optimization.
