Dynaudio Hub Wireless Transmitter at Vinyl Sound Buffalo, NY USA

The Dynaudio Hub is a wireless audio transmitter from Dynaudio (Skanderborg, Denmark), available at Vinyl Sound in Buffalo, NY, USA. Designed as the source hub for Dynaudio's Xeo wireless speaker ecosystem, it accepts multiple analogue and digital audio sources and transmits a lossless wireless digital signal to Xeo 4, Xeo 6, or Dynaudio Link receivers at up to 24-bit/96kHz resolution. Digital inputs include optical, coaxial, and USB, all high-resolution ready. Analogue inputs include a stereo mini jack and RCA stereo. Wireless transmission operates on selectable 2.4 GHz, 5.2 GHz, or 5.8 GHz frequencies with a range of up to 20 metres, and the multi-room function allows a single Hub to feed multiple Xeo speakers simultaneously. No software installation is required.

Lossless Wireless Transmission and Multi-Source Connectivity

The Hub's core function is to receive audio from any connected source and retransmit it wirelessly to Dynaudio Xeo active speakers or a Dynaudio Link receiver without loss of signal quality. The wireless link operates at up to 16-bit/48kHz transmission resolution on the wireless channel, while the digital inputs accept sources at up to 24-bit/96kHz, making the Hub fully compatible with high-resolution audio files from network storage, computers via USB, or disc players via optical or coaxial. The selectable transmission frequency, choosing between 2.4 GHz, 5.2 GHz, or 5.8 GHz, allows the user to select whichever band experiences least interference from other wireless devices in the listening environment, maximising signal reliability in homes with dense Wi-Fi and Bluetooth traffic. Wireless range of up to 20 metres covers typical living room and open-plan installations, with actual range depending on wall materials and construction between the Hub and the receiving speakers. The multi-room function allows a single Hub to simultaneously broadcast to multiple pairs of Xeo speakers in different rooms from a single source selection, enabling whole-home audio from one centralised transmitter without additional network infrastructure or streaming app configuration.

Inputs, Installation, and Power

The Hub provides five source inputs in a compact 140mm x 32mm x 105mm footprint. Digital connections include one optical Toslink input, one coaxial RCA digital input, and one USB input, all supporting up to 24-bit/96kHz. Analogue connections include a 3.5mm stereo mini jack for smartphones, tablets, and portable media devices, and a stereo RCA pair for connection to an existing hi-fi amplifier, CD player, turntable with phono stage, or any line-level analogue source. The Hub requires no software, driver installation, or network configuration. It establishes its own direct wireless connection to paired Xeo speakers at power-on, making it a true plug-and-play source hub. Power is supplied via an included adaptor compatible with 100V to 240V mains, or alternatively via a Micro USB connection at 5V/500mA minimum for flexible placement near a USB power source. Maximum power consumption is just 4W.

Key Features

• Lossless Wireless Digital Transmission: Sends a direct wireless digital signal to Dynaudio Xeo 4, Xeo 6, or Link receivers without audio compression or quality reduction, at up to 16-bit/48kHz on the wireless channel.
• High-Resolution Digital Inputs: Optical, coaxial, and USB digital inputs all support up to 24-bit/96kHz, accommodating high-resolution audio files from computers, disc players, and network sources.
• Dual Analogue Inputs: A 3.5mm stereo mini jack for smartphones and portable devices, plus stereo RCA inputs for turntables with phono preamps, CD players, or any line-level analogue source.
• Selectable Wireless Frequency: Three transmission frequency options, 2.4 GHz, 5.2 GHz, and 5.8 GHz, allow the user to select the cleanest wireless band in their listening environment for stable, interference-free operation.
• Up to 20 Metre Wireless Range: Effective transmission range of up to 20 metres depending on room dimensions and wall construction, covering most domestic listening and living room installations.
• Multi-Room Broadcast: A single Hub can simultaneously feed multiple pairs of Xeo speakers in different rooms, enabling whole-home audio from one source without additional streaming hardware or network configuration.
• Zero Installation Required: The Hub creates its own direct wireless network to paired Xeo speakers at power-on, requiring no software, app, router configuration, or driver installation.
• Flexible Power Supply: Accepts mains power via the included 100-240V adaptor or Micro USB at 5V/500mA for placement near any USB power source. Maximum consumption is just 4W.

Technical Specifications

Frequently Asked Questions

What is the Dynaudio Hub?

The Dynaudio Hub is a wireless audio transmitter designed to connect multiple audio sources to Dynaudio Xeo 4, Xeo 6, or Link active speakers wirelessly. It accepts optical, coaxial, and USB digital inputs at up to 24-bit/96kHz, plus analogue inputs via a 3.5mm mini jack and RCA stereo pair, and transmits a lossless wireless digital signal on selectable 2.4 GHz, 5.2 GHz, or 5.8 GHz frequencies. Range is up to 20 metres, multi-room broadcast is supported, and no software installation is required.

Which Dynaudio speakers does the Hub work with?

The Dynaudio Hub is designed specifically for the Dynaudio Xeo wireless speaker ecosystem, compatible with the Xeo 4 and Xeo 6 active wireless speakers and the Dynaudio Link wireless receiver. It is not compatible with Dynaudio Focus, Evoke, Contour, Emit, or other passive or non-Xeo active speakers, as those use different wireless transmission protocols and connectivity platforms.

Does the Dynaudio Hub require a Wi-Fi network or router?

No, the Hub creates its own direct wireless connection to paired Xeo speakers and does not require a Wi-Fi router, network configuration, or any software installation. It operates independently of a home network, using its own dedicated wireless link on 2.4 GHz, 5.2 GHz, or 5.8 GHz. This makes it straightforward to set up and eliminates any dependency on home network performance or congestion for audio transmission reliability.

Can the Dynaudio Hub stream music from a smartphone or tablet?

Yes, in two ways. A smartphone, tablet, or other portable device can be connected directly via the 3.5mm analogue mini jack input on the Hub, sending audio from any app or player to the connected Xeo speakers. The Hub also accepts digital audio via its USB input, which can receive digital audio output from a computer or USB audio device. For wireless streaming directly from a phone or tablet without a physical connection to the Hub, the Xeo system requires a Dynaudio Connect device rather than the Hub alone.

What wireless frequency should I select on the Dynaudio Hub?

The Hub offers three wireless frequency options: 2.4 GHz, 5.2 GHz, and 5.8 GHz. If the listening environment has significant 2.4 GHz traffic from Wi-Fi routers and Bluetooth devices, selecting 5.2 GHz or 5.8 GHz will typically reduce interference and improve transmission stability. The 5 GHz band options are generally less congested in domestic environments. If the Hub and Xeo speakers are in a room with no other 2.4 GHz interference, that band provides the widest availability. Simply select whichever frequency provides the most stable wireless connection in the specific installation.

Where can I buy the Dynaudio Hub in Buffalo, NY or the USA?

The Dynaudio Hub is available at Vinyl Sound in Buffalo, NY, USA. Vinyl Sound is an authorized Dynaudio dealer serving customers in Buffalo, Western New York, and across the United States. Contact Vinyl Sound Buffalo to discuss Xeo system configuration or to pair the Hub with compatible Xeo active speakers.
