LEBEN CS-300X(S) - EL84 TUBES INTEGRATED AMPLIFIER

$4,995.00

Product Details

Small and Powerful with a Famous Sound

CS-300X(S) is equipped with SOVTEK Tube EL-84, which is well-known by audiophiles for its small size and incredible sound.
The high input sensitivity of EL84 tubes does not require a complicated circuit, and through this, it can create a signal with incredibly low levels of distortion.

HIGHEST-END AUDIO GRADE COMPONENTS

RESISTORS: Precision Industrial Grade +/-1%
FIRST-STAGE BY-PASS CONDENSOR: An ultimate audio condensor "OS Condensor" developped by "SANYO"
LAST-STAGE BY-PASS CONDENSOR: "Fine-Gold" by "NICHICON"
JOINT CONDENSOR: "Metalized Polypropylene Condensor" with "Mesh-Shielding".
NF OVERSHOOT PREVENTION CONDENSOR: Ceramic Conderser.
CATHODE RESISTOR: 4W type.(Instead of 3W type)
OUTPUT TRANSFORMER: Newly developped Transformer with wider range for high frequency.
WBT type binding post.(From April/05 delivery onward)/li

FIVE INPUTS
CS-300X(S) IS EQUIPPED WITH 5 LINE INPUTS PLUS TAPE MONITOR.

OTHER LUXURIOUS PARTS

Tube Shield-Base: 24K gold plated.
SIDE-WOOD PANEL: Canadian White-Ash".

FULL FUNCTIONS FOR INTEGRATED AMP.

TAPE MONITOR.
HEADPHONE OUTPUT.
BASS BOOST SWITCH
SPEAKER/HEADPHONE SELECTOR.
VARIABLE OUTPUT IMPEDANCE: 4/6/8 OHMS.
Operation Lamp Indicator.
On-Switch Power Indicator LED.

CS-300X(S) SPECIFICATIONS

TUBES EQUIPPED	EL84(SOVTEK) X 4 12AX7A(Sovtek) X 2
OUTPUT POWER	15W X 2
FREQUENCY RESPONSE	15Hz - 100KHz (-2 dB)
DISTORTION	0.7%(10W)
INPUT SENSITIVITY	600mV
INPUT IMPEDANCE	100K Ohms
OUTPUT IMPEDANCE	4/6/8 Ohms (Selectable)
POWER CONSUMPTION	82W
WEIGHT	10.5 Kgs.
DIMENSIONS	360 (W) X 270 (D) X 140 (H) mm
ATTACHMENT	Detachable AC Power Cable x 1
