CASTLE WINDSOR EARL WITH STANDS

$4,995.00

Color
Walnut
Mahogany
Quantity

Product Details

The Windsor Earl is equipped with an 6” woofer, purposely-developed together with a 28mm textile dome tweeter, to perform seamlessly in a classic bookshelf / monitor styled cabinet.

The drive units have all been engineered from the ground up, using cast alloy components, yet retaining the essential character through the use of new woven Polypropylene cones and glass-fibre voice coils.

The cabinet work is, as you would expect from a product bearing the Castle name, first class. The hand-selected, book-matched pairs of veneers are sourced from the original suppliers to ensure continuity in the Castle legacy. Our dedicated ‘hand – finished’ team is trained to deliver the highest quality ‘furniture – grade’ finishes and build. No two pairs are the same!

Made in the UK

Castle are proud to announce the Windsor Series, signalling the return to the UK for the manufacturing of Castle Loudspeakers. Castle Windsor Series comes, with the craftsmanship and quality that is self-evident and clearly marks the brand’s intention to restore and build upon the reputation of the brand for superlative quality loudspeakers.

Echoing the origins of the brand that was established in 1973; the speakers are hand built and hand finished, by our loudspeaker production experts, in England.

A Collaborative Development:

To ensure the Windsor Series is truly something special, Castle has harnessed the talents of world- renowned speaker designer Karl-Heinz Fink and his Fink Audio team. Built over decades, Fink’s track record of developing excellent loudspeakers is exceptional, He was recently described as “today’s most influential speaker designer” when presented with the Outstanding Contribution Award at the What Hi-Fi? Awards 2022 – a fitting tribute to the success of his designs.

Windsor Highs

The frequency unit follows the classical formula of a high-consistency exposed polyester dome, with a pressure equalised Ferrite magnet system and a stable metal front plate. No Ferrofluid is used in the tweeter in order to guarantee the highest possible dynamic range. This also keeps the resonant frequency below 800Hz, for optimum performance.

The treble unit’s voice coil has a diameter of 28mm and is equipped with a copper cap on the pole piece of the magnet. This reduces distortion and intermodulation, delivering a tangible increase in audible detail at very high frequencies.

A Royal Weave

The Polypropylene used in the cones is precision cut into thin strips, woven back into a sort of fabric and comes together again to form a solid foil. This foil gets pressed into the final shape and then cut to size.

This is a much more complex way of creating a polypropylene cone, but it has significant sonic benefits. The process creates a material with different properties of rigidity, at different directions between the voice coil and the surround. This helps to minimise resonances, which produces a flatter response curve – a desired characteristic of any drive unit designed for high-performance audio.

The resulting cones, with a diameters of 165mm, feature surrounds fashioned from low-hysteresis rubber which will not deteriorate over time.

Improved openness of the midrange performance

The magnet system in the Castle Windsor Series includes an aluminium compensation ring. This ring helps minimise the variation of the impedance during the operation of the drive unit. As a result, the harmonic and intermodulation distortion values are reduced, for improved openness of the midrange performance.

Maintaining purity of signal

The voice coils are made from glass fibre, bonded with high-temperature resin – the stiffness and rigidity of this material is extremely close to that of aluminium, but it doesn’t generate eddy currents like aluminium would. Thus, it maintains signal purity by its very design.The mid/bass drivers’ magnet system includes an aluminium compensation ring, which helps to minimise impedance variations during operation. As a result, the harmonic and intermodulation distortion values are reduced, contributing greatly to an open and expressive midrange performance.

Specifications:

Model Windsor Earl
General Description 2-way Bookshelf Speaker
Enclosure Type Bass Reflex
Transducer Complement 2-Way
Bass Driver 6.5"(165mm) Woven Polypropylene
Treble Driver 1.1" (28mm) Micro-Fibre Dome
Sensitivity (2.83V@1m) 89dB
Recommended Amplifier Power 25-100W
Peak SPL 95dB
Nominal Impedance 8Ω Compatible
Minimum Impedance 4.3Ω
Frequency Response (+/-3dB) 58Hz - 22kHz
Bass Extension (-6dB) 45Hz
Crossover Frequency 2.2kHz
Cabinet Volume 15.8L
Dimensions (HxWxD) 430 x 240 x (260+36) mm
Finish Mahogany Veneer
