Gold Note P-1000 Line Pre Amplifier
$8,999.00
Product Details
Ultra-balanced Class-A line preamplifier
The Gold Note P-1000 Line features proprietary Six Single Gain Stage Ultra-Balanced design with Triple Linear Transformer power supply. 10 independent stereo inputs (5× XLR balanced, 5× RCA unbalanced) plus optional digital input for complete analog control.
Six Gain Stage architecture
Ultra-linear 2Hz-200kHz ±3dB bandwidth, <0.001% THD @1kHz, -120dB SNR, >118dB channel separation. Relays + Optical ALPS encoder 0.5dB step volume control preserves signal purity across entire dynamic range.
Comprehensive analog matrix
5× XLR balanced (10Vrms max), 5× RCA unbalanced (10Vrms max) inputs with 100kΩ impedance. Outputs: XLR balanced (16Vrms max), RCA unbalanced (8Vrms max) with <10Ω output impedance. Memory stores settings per input.
Advanced analog processing
Mono/Stereo selection, L/R channel swap, 0°/180° absolute phase inversion. Proprietary Booster technology provides 3-level 50Hz bass enhancement (fully bypassable). Fine Balance control for precise imaging optimization.
1000 Series control interface
Large color SKC display shows all functions instantly. Remote control, rotary knob, USB firmware updates. Power consumption 30W max. Dimensions: 430×130×375mm, 11kg net. Expandable with TUBE-1006/1012 and PSU-1000/1250.
Perfect analog command center
Ideal match for Bellagio turntables, B-7 Ceramic tonearms, Tuscany cartridges, and PA-1175 MkII amplifiers. Available exclusively at Vinyl Sound Buffalo, NY.
Technical Specifications
| Parameter | Value |
|---|---|
| Design | Class-A Six Single Gain Stage Ultra-Balanced |
| Frequency Response | 2Hz-200kHz ±3dB |
| THD | <0.001% @1kHz |
| SNR | -120dB |
| Channel Separation | >118dB |
| Gain | +20dB |
| Analog Inputs | 5× XLR balanced, 5× RCA unbalanced (10Vrms max) |
| Input Impedance | 100kΩ |
| Outputs | XLR (16Vrms max), RCA (8Vrms max) |
| Output Impedance | <10Ω |
| Volume Control | 0.5dB steps, Relays + Optical ALPS encoder |
| Processing | Mono/Stereo, L/R swap, Phase 0°/180°, 3-level Booster |
| Power Supply | Triple Linear Transformer (Dual Mono) |
| Power Consumption | 30W max |
| Dimensions (WxHxD) | 430 × 130 × 375mm |
| Weight | 11kg net |
Ultimate analog preamplifier foundation
Modular upgrade path: TUBE-1006/1012 valve stages, PSU-1000/1250 external supplies. Perfect command center for complete Gold Note analog systems. Contact Vinyl Sound Buffalo for Booster optimization and system design.
