NAD CI SA2-120 BluOS Streaming Amplifier Module - ETA April

$1,899.00

Product Details

NAD CI SA2-120 BluOS Streaming Amplifier Module

DESCRIPTION

The NAD CI SA2-120 BluOS Streaming Amplifier Module is a compact, rack-friendly powerhouse for custom installations, delivering flexible high-performance amplification and multi-room streaming. With NAD’s DirectDigital™ technology, it provides 2 × 120W or 4 × 60W of clean, detailed power, optimized by Dynamic Power Management for any speaker load or cable run. BluOS integration unlocks 20+ streaming services, internet radio, and high-res playback, while automation compatibility ensures seamless control with Control4, Crestron, Lutron, and more. Features include HDMI eARC, Ethernet, Wi-Fi, aptX HD Bluetooth, Dirac Live readiness, and Domotz remote monitoring. A slim 1U/3-width chassis with ChassisLink, Phoenix connectors, thermostatic cooling, and versatile mounting options makes the CI SA2-120 the ultimate choice for scalable, reliable, custom audio installs.

NAD CI SA2-120 BluOS Streaming Amplifier Module

★★★★★

$1,599.00

Dedicated Support from Start to Finish

Concierge-Level Experience tailored to your needs
Assistance with Troubleshooting and Product Insights
Expert help for Product Set-Up
Free Shipping on all orders

FEATURES

2 x 120 W or 4 x 60 W DirectDigital™ amplification
Dynamic Power Management automatically optimises power distribution
BluOS Enabled multi-room streaming with access to 20+ services and internet radio
Dirac Live Ready for room correction
Main Zone/Sub Zone configuration with independent volume control
Compact 1/3 width x 1U height with ChassisLink
aptX HD two-way Bluetooth, AirPlay 2, Spotify Connect, and Tidal Connect
Inputs: HDMI eARC, combo analogue/ digital input
Outputs: Subwoofer output, snap-on Phoenix speaker connection blocks
Dual-band Wi-Fi and Gigabit Ethernet
Programmable 12 V Trigger In
IR input with learning via BluOS (IR extender kit required)
Universal AC power supply
Thermostatic fan cooling with front-to-rear airflow for reliable stacking
Flexible rack and surface placement options
Robust drivers for Control4, Crestron, URC, RTI, NICE, Lutron, and KNX
Remote monitoring via Domotz

Included Accessories

120V AC Power Cord
230V AC Power Cord
2 x Short rack ears (also used as wall mount brackets)
2 x Long Rack ears/
Blacnking plates
2 x Shoulder Bolts + 2 x Rubber Washers (already attached for ChassisLink)
2 x 4-PIN Snap On PHX 5.08mm Speaker Connectors
1 x 4-PIN PHX Connector for 12v trigger + IR In
4x optional stick on rubber feet
Wi Fi Antenna
BT Antenna

TECHNICAL SPECS

Supported Audio File Formats: MP3, AAC, WMA, WMA-L, OGG, OPUS
Supported High-Quality Audio File Formats: FLAC, MQA, ALAC, WAV, AIFF, MPEG-4 SLS
Supported Multi-Channel Audio Formats: Dolby Digital® Downmixing to stereo PCM
Native Sampling Rates: up to 192 KHz
Bit Depth: 16-24
Audio Controls & EQ: BluOS Control App
Signal-to-Noise Ratio: -102dBA
Distortion: THD+N, 0.005%
Amplification: DirectDigital™
Rated Power Output: Dynamic Power Management - 120W x 2 or 60W x 4 (8 Ohms)
IHF Dynamic Power: 300W (4ohm)/200w (8ohm)
Operating System: BluOS
App Controller Operating System: iOS, Android, Windows, macOS
Processor: ARM® Cortex™ -A53, Quad-Core, 1.8GHz per core
Supported Network File Sharing: Server Messsage Block (SMB) up to 200,000 files
Album Art Supported: JPG, PNG
Music Services & Internet Radio: 23+
3rd-Party Integrations: AirPlay 2, Spotify Connect, Tidal Connect
Room Correction Software: Dirac Live Ready (In 2.1 configuration only, calibration mic not included)
Control System Integrations: Creston, Control4, RTI, Nice, URC, Lutron, Gira, Rako, Rithum, Free@Home, Josh.AI
Voice Control Integrations: Amazon Alexa Skills
Power Supply: Universal 2-pin AC cord input (100-240AC)
Ethernet/LAN: Ethernet RJ45, Gigabit 1000Mbps
Wi-Fi Built In: WiFi 5 (802.11ac), dual-band
Bluetooth Quality: Bluetooth 5.2 aptX HD
Bluetooth Connectivity: Two-Way
IR Optical Built In: No
IR Input: 2-pin PHX connector (IR extender kit required)
Optical/Analog Input: Toslink Optical, 3.5mm Analog
HDMI Input: HDMI eARC
USB In: Type A (Fat32, NTFS Formatted) - External Storage Only Local Server Mode
Dual Speaker Outputs: Yes
Main Zone/Sub Zone Capability: Yes (independent volume control over Speaker Output 2 when activated)
Subwoofer Output: RCA x 1; Wireless to PULSE SUB+ (Linked to Output1/Main Zone only)
Speaker Terminals: 2x 4-PIN Snap On PHX 5.08mm Connector, supports up to 12AWG
Headphone Output: None
12v Trigger Input: x1 Programmable Trigger Input
12v Trigger Output: None
Max Power Consumption: 240W
Storage Environment: -10°C to 50°C, 20% to 80% relative humidity
Operating Environment: 0°C to 40°C
Product Dimensions: 146.5 x 44 x 384 mm | 5.77 x 1.73 x 15.11 inches
Product Weight: 2.52 kg/5.56 lbs
