WHARFEDALE DIAMOND 12 3D 2-WAY VERTICAL CHANNEL

$349.00 $449.00

Pay as per month with Affirm

Product Details

Add to shopping cart is not available for all Wharfedale Products, Please call or email us to place your orders.



Since 1982, Wharfedale’s famous DIAMOND speakers have served as the classic entry point to true high-fidelity sound, their exceptional sonic value for money earning numerous ‘product of the year’ accolades in the UK and around the world. This autumn, with the introduction of the all-new DIAMOND 12 Series, Wharfedale once again raises the bar for affordable, high-performance loudspeakers.

With this newest addition to the record-breaking, award-winning DIAMOND 12 series, Wharfedale takes surround sound to the next level with the DIAMOND 12 3D surround speaker.

Covering the audience in a dome of sound, following Wharfedale’s long history in cinematic and home theatre solutions, you can now have a 3D cinema-audio listening experience at home with your DIAMOND 12 series configuration.

Klarity affords focus

As with all DIAMOND 12 models, the DIAMOND 12 3D uses the famed KlarityTM polypropylene cones that renowned for their characteristically low distortion and controlled ‘breakup’.

Low colour and expression

To make KlarityTM, Wharfedale adds mica to the formulation. This increases stiffness compared to polypropylene alone, reducing flexing and enabling a lightweight cone with high rigidity, low colouration and lightning-fast response – ideal characteristics to deliver both accuracy and excitement.

A magnet of forces

The KlarityTM diaphragms are driven by a substantial, precision-made magnet system with an aluminium compensation ring to minimise the effect of variations in inductance as the voice coil travels. This contributes to an absence of distortion and intermodulation generated by the motor system.

A voice coil beyond this class

The voice coil is wound on a high-power epoxy/glass fibre bobbin – highly unusual in speakers at this price level. This has the advantage of not adding eddy currents and delivering greater power handling than an aluminium bobbin, whilst also being much stiffer than the Kapton type.





A voice coil beyond this class

The voice coil is wound on a high-power epoxy/glass fibre bobbin – highly unusual in speakers at this price
level. This has the advantage of not adding eddy currents and delivering greater power handling than an
aluminium bobbin, whilst also being much stiffer than the Kapton type

DIAMOND highs

The 25mm dome made from a woven polyester film with a high-loss
coating to deliver open and smoothly extended high frequencies. The magnet system and the front plate
have been optimised for wide dispersion and uncompressed behaviour. The front plate is flat and exposes
the dome as much as possible, with a short duct to balance the acoustic load and improve the SPL (sound
pressure level) measurement.





Brace yourself

Inside the cabinet, Intelligent Spot Bracing connects opposing walls
with a specific form of wood brace to achieve optimal reduction of
cabinet resonance. These braces are precisely modelled by
computer simulation to improve upon the commonplace ‘figure of
eight’ brace, which can have the effect of transferring resonance from one wall to another.
